A 93 Canol gas-fired frying line

Manufactorer: Canol

Model: 400/1000 GBP CDMM, 2994

Year: 2021

Capacity: 4050 pcs/h depending on product

Consisting of:

Automatic loading station

400GBP fryer

PALLADIO filtration unit

Gravity oil filtration unit

GLOBUS filling unit

Glazing station

TECHNICAL DATA – FRYER

Working width: 1,000 mm

Working length: 4,000 mm

Oil tank capacity: approx. 510 litres

Installed electrical power: 12.8 kW

Total heating capacity: approx. 140 kW (approx. 120,000 kcal)

Frequency: 50 Hz

Power supply: 400 V / 3 Phases + N + Ground

Construction: Stainless steel

HEATING SYSTEM

Fuel: Natural gas (methane)

Heating system: Heat exchange system with a double-bottom oil tank using thermal oil

Burners: 4 gas burners

Preheating system: RIELLO combustion heads

PRODUCTION DATA

Product turning stations: 3

Rod stroke: 127 mm

Suitable product diameter: Ø 90–95 mm

Number of rows:

Production capacity: approx. 4,050 pcs/hour

Frying time: approx. 240 seconds
